Winters 2-1/2 inch Dial Size, Economy Utility Pressure Gauge, Potable Brass Internals, Steel Case, Dual Scale 0-100 psi/kPa, 3-2-3% Accuracy, 1/4 inch NPT Bottom Mount, Drinking Water Pressure Gauge
Product details
| Management number | 221614222 | Release Date | 2026/05/03 | List Price | US$8.74 | Model Number | 221614222 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Applications: Plumbing, heating, air conditioning, pneumatic, water tanks, air compressors, OEM. Most economical, all-purpose pressure gauge. CRN registered. Dial: White aluminum with black and red markings. Case: Steel, painted black. Ring: Steel, painted black. Lens: Polycarbonate. Bourdon Tube: Lead free phosphor bronze. Socket: Lead Free Brass. Movement: Brass. Working Pressure: Maximum 75% of full scale value. Over-Pressure Limit: 25% of Full Scale Value. Enclosure Rating: IP52. Accuracy: ±3-2-3% ANSI/ASME Grade B. Dial Size: 2.5” (63mm). Range: 0-100 PSI/KPA. Connection: 1/4" NPT Bottom Connect.
- Most economical, all-purpose pressure gauge
- Lead free wetted parts
- 2.5" Dial Size
- ±3-2-3% accuracy
- Black Steel Case
| UPC | 628311202649 |
|---|---|
| Model | PEM214LF |
| Brand Name | Winters Instruments |
| Unit Count | 1.0 Count |
| Item Weight | 3.84 ounces |
| Part Number | PEM214LF |
| Manufacturer | Winters |
| Thread Style | National Pipe Thread (Npt) |
| Material Type | Aluminum,Phosphor Bronze,Polycarbonate,Steel,Brass |
| Item Dimensions | 3.1 x 2.5 x 1.2 inches |
| Included Components | Unit and Instruction Guide |
| Global Trade Identification Number | 00628311202649 |
